A un vistazo
Adopt high quality components of ST,IR and Infineon, make sure product using lifespan
Terminals have UL and VDE certification, the product is more safer and more reliable
Controller can work continuously at full load within the environment temperature range from -25 to 55
°C
3-Stage intelligent PWM charging
:
Bulk, Boost/Equalize, Float
Support 3 charging options: Sealed, Gel, and Flooded
LCD display design, dynamically displaying device’s operating data and working condition
Double USB design, the power supply charge for electronic equipment
With humanized button settings, operation will be more comfortable and convenient
Multiple load control modes
Energy statistics function
Battery temperature compensation function
Extensive Electronic protection
Detalles del producto
Preguntas y respuestas sobre este producto
Resuelve tus dudas preguntando a la comunidad y a nuestro equipo de servicio al cliente.
Especificaciones
| Peso y dimensiones | |
|---|---|
| Altura | 59.8 mm |
| Profundidad | 100.9 mm |
| Peso | 580 g |
| Ancho | 181 mm |
| Condiciones ambientales | |
|---|---|
| Intervalo de temperatura operativa | -25 - 55 °C |
| Características | |
|---|---|
| Código IP (International Protection) | IP30 |
| Corriente de carga | 30A |
| Pantalla incorporada |
|
| Tipo de control | Botones |
| La tensión de carga | 12 - 48V |
| Tipo de visualizador | LCD |
