La licencia es aplicable a los siguientes productos:
A un vistazo
Universal AC input / Full range
Protections: Short circuit/Overload/Over voltage
Cooling by free air convection
LED indicator for power on
100% full load burn-in test
All using 105 °C long life electrolytic capacitors
Withstand 300VAC surge input for 5 second
High operating temperature up to 70°C
Withstand 5G vibration test
No load power consumption<0.5W
High efficiency, long life and high reliability
3 years warranty
Detalles del producto
Preguntas y respuestas sobre este producto
Resuelve tus dudas preguntando a la comunidad y a nuestro equipo de servicio al cliente.
Especificaciones
| Peso y dimensiones | |
|---|---|
| Altura | 36 mm |
| Profundidad | 99 mm |
| Ancho | 97 mm |
| Detalles técnicos | |
|---|---|
| Color del producto | Negro, Metálico |
| Control de energía | |
|---|---|
| Tiempo de espera | 60 ms |
| Frecuencia de entrada AC | 47/63 Hz |
| Funciones de protección de poder | Sobrevoltaje, Sobrecarga, Cortocircuito |
| Potencia total | 75W |
| Eficiencia | 88% |
| Diseño | |
|---|---|
| Indicadores LED | Poder |
| Condiciones ambientales | |
|---|---|
| Intervalo de humedad relativa durante almacenaje | 10 - 95% |
| Intervalo de temperatura operativa | -25 - 70 °C |
| Intervalo de temperatura de almacenaje | -40 - 85 °C |
| Intervalo de humedad relativa para funcionamiento | 20 - 90% |
