La licencia es aplicable a los siguientes productos:
A un vistazo
Detection Range: 12m / 85.9°
Up to 10kg pey immunity within 10m
Optional/Automatic sensitivity
Digital temperature compensation
52 zones of 3D optics including creep-zone protection, full coverage without dead angle
selectable EOL resistors for alarm and tamper-proof wiring
Sealed optics preventing insect interference
24Ghz microwave
Global certifications available (EN Grade2/CE/FCC/CB/CCC/IC/RCM)
9 to 16 V wide voltage adaptation with polarity reverse connection protection
Wall/Ceiling-mounting brackets available (sold separately)
IFT technology prevents false alarms
Detalles del producto
Preguntas y respuestas sobre este producto
Resuelve tus dudas preguntando a la comunidad y a nuestro equipo de servicio al cliente.
Especificaciones
| Peso y dimensiones | |
|---|---|
| Altura | 103.8 mm |
| Profundidad | 45.5 mm |
| Peso | 99 g |
| Ancho | 65.7 mm |
| Detalles técnicos | |
|---|---|
| Ángulo de detección | 85.9° |
| Indicadores LED |
|
| Sensitivilidad de la luz | 6500 Lux |
| Tipo de montaje | Pared |
| Control de energía | |
|---|---|
| Alimentación | CC |
| Consumo de energía | 17 mA |
| Condiciones ambientales | |
|---|---|
| Intervalo de temperatura operativa | -10 - 55°C |
| Intervalo de temperatura de almacenaje | -20 - 60 °C |
| Intervalo de humedad relativa para funcionamiento | 10 - 90% |
| Seguridad | |
|---|---|
| Tipo de sensor | Microondas |
| Distancia de detección | 12 Metros |
| Inmunidad a mascotas (máx.) | 10 kg |
