A un vistazo
Optional/Automatic sensitivity
On-board EOL resistors. No need to add external resistors, which reduces the construction cost
Supports single/double EOL resistors
52 zones 3D optics including creep-zone protection, full coverage without dead angle
Sealed optics preventing insect invasion
Global certifications available (EN/CE/FCC/CB/CCC/IC/RCM/KC/LOA)
Blue LED indicator for displaying alarm events, On/Off configurable
9 to 16 V wide voltage adaptation with polarity reverse connection protection
Wall/Ceiling-mounting brackets available (sold separately)
Digital temperature compensation
Detalles del producto
Preguntas y respuestas sobre este producto
Resuelve tus dudas preguntando a la comunidad y a nuestro equipo de servicio al cliente.
Especificaciones
| Peso y dimensiones | |
|---|---|
| Altura | 86.8 mm |
| Profundidad | 45.5 mm |
| Peso | 68 g |
| Ancho | 65.4 mm |
| Detalles técnicos | |
|---|---|
| Ubicación | Interior |
| Ángulo de detección | 85.9° |
| Indicadores LED |
|
| Altura de instalación (min) | 1.8 m |
| Sensitivilidad de la luz | 6500 Lux |
| Tipo de montaje | Techo/pared |
| Altura de instalación (max) | 2.4 m |
| Control de energía | |
|---|---|
| Voltaje de entrada | 9 - 16 V |
| Alimentación | CC |
| Consumo de energía | 20 mA |
| Condiciones ambientales | |
|---|---|
| Intervalo de temperatura operativa | -10 - 40°C |
| Seguridad | |
|---|---|
| Tipo de sensor | PIR |
| Distancia de detección | 18 Metros |
